| Model | Standard Model | |||
| ThermoStable OF-50 | ThermoStable OF-105 | ThermoStable OF-155 | ||
| Window Model | ||||
| ThermoStable OF-W105 | ThermoStable OF-W155 | |||
| Capacity | 50Lit | 105Lit | 155Lit | |
| Dimension
(w×d ×h) |
Interior (mm) | 370×345×420 | 485×415×535 | 550×480×600 |
| Exterior (mm) | 518×647×724 | 653×712×882 | 718×777×947 | |
| Heater Power | 650 W | 1.4 kW | 1.6 kW | |
|
|
Range | Ambient Temperature +5℃ to 250℃ | ||
| Fluctuation | ±0.3℃ at 100℃, ±0.5℃ at 150℃ | |||
| Variation | ±1℃ at 100℃, ±1.8℃ at 150℃ | ±1℃ at 100℃, ±2℃ at 150℃ | ||
| Sensor | PT 100 | |||
| Control Resolution | ±0.1℃ | |||
| Heat-up Time | 25 min. to 100 ℃,
45 min. to 150℃ |
25 min. to 100 ℃,
40 min. to 150℃ |
||
| Recovery Time (Door open 30sec) | 8 min. to 100 ℃,
8 min. to 150℃ |
6 min. to 100 ℃,
6 min. to 150℃ |
||
| Controller | Digital Fuzzy Control by Advanced Microprocessor Jog-Dial with Push Button | |||
| RS232 Port | Available to connect with PC | |||
| Display | Digital LCD with Back Light | |||
| Timer | 99hr 59 min (delay/continuous function) | |||
|
Material |
Internal | Stainless steel (#304) | ||
| External | Powder Coated steel | |||
| Insulation | Glass Wool | |||
| Shelves | 2ea of Stainless steel Wire Shelves included, Load per Shelf : 16 kg | |||
| Ventilation | Ventilation hole with Stainless steel Cap, Hole Diameter 40mm | |||
| 1ea | 2ea | |||
| Circulation | Forced Air Convection Type | |||
| Safety device | Over Temp. and Over Current Protector, Sensor Error Detector | |||
|
Others |
UL/CUL Certified, CE Certified, GD-mark Storage Function (Temp. and Time) Locking Mode (Jog-Dial Input Disabled) Alarm (Error Status and Timer-end) | |||
| Net Weight (kg) | 44 | 69 | 78 | |
| Packing Size (w×d×h) (mm) | 622×754×807 | 743×819×1,068 | 808×884×1,133 | |
| Shipping Weight (kg) | 59 | 79 | 92 | |
| Power Consumption | 674 W | 1390 W | 1566 W | |
| Energy Consumption, at 100°C
, at 150°C |
117 Wh | 187 Wh | 204 Wh | |
| 230 Wh | 337 Wh | 398 Wh | ||
| Power Supply | 1Phase 120V, 60Hz or 230V, 50/60Hz | |||
